RIX LPR L6R Thermal Scope

RIX LPR L6R 640×512 Thermal Imaging Riflescope with Laser Rangefinder

The RIX LPR L6R Thermal Scope is a new-generation thermal imaging riflescope combining a high-sensitivity 640×512 thermal sensor, 50mm F0.9 objective lens, continuous optical zoom and an integrated laser rangefinder. Designed for demanding outdoor use, it delivers detailed thermal images, accurate distance readings and advanced image processing in one compact optical system.

At the heart of the RIX LPR L6R is a 12µm thermal sensor with an impressive NETD of less than 12mK, allowing it to pick up subtle temperature differences and produce clear images in challenging weather conditions. The large-aperture 50mm F0.9 lens works alongside RIX ClarityX image processing to maintain excellent image definition and detail.

With continuous optical magnification from 3x to 9x, a high-resolution 2560×2560 AMOLED display and a built-in laser rangefinder capable of measuring distances up to 2,187 yards, the LPR L6R brings together the latest RIX thermal technology.

For anyone looking at the latest RIX thermal scopes or comparing new thermal imaging optics with integrated rangefinders, the LPR L6R offers an impressive combination of optical performance, intelligent features and practical design.

Key Features of the RIX LPR L6R Thermal Scope

• 640×512 Thermal Sensor: High-resolution thermal imaging with excellent image detail.

• NETD Below 12mK: Exceptional thermal sensitivity for detecting subtle temperature differences.

• 50mm F0.9 Objective Lens: Large-aperture lens designed to capture more thermal information.

• Continuous Optical Zoom: Smooth magnification from 3x to 9x.

• Integrated Laser Rangefinder: Measures distances up to 2,187 yards.

• 2560×2560 AMOLED Display: High-resolution 1.03-inch display for detailed viewing.

• ClarityX Image Processing: Advanced image enhancement for improved definition.

• Magnesium Alloy Housing: Lightweight and durable construction, approximately 30% lighter than the previous LEAP series.

• Ballistic Calculation: Integrated ballistic calculation supported by environmental sensors.

• RIX+ App Connectivity: Wi-Fi connection for image streaming, device settings and firmware updates.

• Recoil Activated Recording: Automatically captures footage when recoil is detected.

• Picture-in-Picture: Provides a magnified central image while retaining the surrounding view.

Advanced 640×512 Thermal Imaging

The RIX LPR L6R features a high-performance 640×512 thermal sensor with a 12µm pixel pitch and NETD below 12mK. This combination provides excellent thermal sensitivity, helping reveal differences in temperature and retain image detail in difficult environmental conditions.

The 50mm F0.9 objective lens provides excellent light collection for thermal imaging, while RIX ClarityX image processing enhances definition and contrast.

Continuous 3x–9x Optical Magnification

Unlike thermal scopes that rely heavily on digital magnification, the RIX LPR L6R offers continuous optical zoom from 3x to 9x.

The smooth magnification adjustment makes it easier to move between different viewing levels, with additional digital zoom available when required. Conveniently positioned controls allow straightforward adjustment.

Integrated Laser Rangefinder – Up to 2,187 Yards

The built-in laser rangefinder measures distances up to 2,187 yards, providing useful distance information without requiring a separate ranging device.

Features include:

• Integrated laser rangefinder.

• Single and continuous ranging modes.

• Mechanically adjustable laser alignment.

• Integrated ballistic calculation functions.

• Environmental monitoring sensors.





High-Resolution 2560×2560 AMOLED Display

The 1.03-inch AMOLED display offers a resolution of 2560×2560, providing a detailed viewing experience through the eyepiece.

Additional viewing features include:

• Picture-in-Picture mode.

• Adjustable brightness and contrast.

• Image sharpness adjustment.

• Weather-specific image modes.

• Multiple reticle designs and colours.

• Customisable stored profiles.

Lightweight Magnesium Alloy Construction

RIX has designed the LPR L6R with a magnesium alloy housing to reduce overall weight by approximately 30% compared with the previous LEAP series.

The 30mm tube construction provides compatibility with suitable mounting systems, while the robust housing is designed for demanding outdoor conditions.

Intelligent Recording and RIX+ Connectivity

The LPR L6R includes several smart features designed to make recording and device management straightforward.

• Recoil Activated Video: Automatically records footage when recoil is detected.

• Recoil to Zoom: Switches to a preset magnification following recoil.

• Wi-Fi Connectivity: Connects to compatible smartphones.

• RIX+ Application: Supports image streaming, device configuration and firmware updates.

• Environmental Sensors: Monitors temperature, humidity and atmospheric pressure.



RIX LPR L6R Thermal Scope – Technical Specifications

What’s Included in the Box?

• 1 x RIX LPR L6R Thermal Riflescope

• 1 x 30mm Rings Picatinny Mount

• 1 x Slotted Screwdriver for LRF Adjustment

• 1 x Battery Charger

• 2 x 21700 Batteries

• 1 x 18650 Battery Adapter Sleeve

• 1 x Battery Fireproof Bag

• 1 x USB Type-C Cable

• 10 x Thermal Targets

• 1 x Hex Key

• 1 x Lens Cloth

• 1 x Set of Protective Stickers
